Products specifications

Category Discrete Semiconductor Products - Diodes - Zener - Single Zener Diodes
Mfr Microchip Technology
Package Bulk
Product Status Active
Voltage - Zener (Nom) (Vz) 3.3 V
Tolerance ±5%
Power - Max 500 mW
Impedance (Max) (Zzt) 28 Ohms
Current - Reverse Leakage @ Vr 25 µA @ 950 mV
Voltage - Forward (Vf) (Max) @ If 1.5 V @ 200 mA
Temperature Range - Operating -65°C ~ 175°C (TJ)
Mounting Type Through Hole
Package / Case DO-204AH, DO-35, Axial
Supplier Device Package DO-35 (DO-204AH)
Standard Package 1 pcs
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0050
Win Source Part Number 539170-1N5226
Ultra Librarian 3D Model Ultra Librarian 1N5226 CAD Model

Description

Product Overview: 1N5226 Zener Diode from Microchip Technology

The 1N5226 is a reliable Zener diode produced by Microchip Technology, designed to offer excellent voltage regulation with a nominal Zener voltage of 3.6 volts. This component is a staple in electronic circuits where precision voltage clamping or reference voltages are required. The 1N5226 comes in a DO-35 package, which is a small and durable glass package suitable for through-hole mounting, making it a versatile choice for various electronic applications.

Key Features

  • Zener Voltage: The 1N5226 provides a precise Zener voltage of 3.6V, which is ideal for voltage regulation in a wide range of circuits.
  • Power Dissipation: It has a power dissipation rating of 500 milliwatts, ensuring reliable operation under standard conditions.
  • Tolerance: The Zener voltage tolerance is ±5%, which allows for predictable performance in your circuits.
  • Operating Temperature: This diode can operate efficiently across a wide temperature range, typically from -65°C to 175°C, making it suitable for various environments.
  • Package Type: Packaged in the industry-standard DO-35, the 1N5226 is easy to install and handle in different types of electronic equipment.

Applications

The 1N5226 Zener diode is used in a multitude of applications, including:

  • Voltage regulation in power supplies
  • Surge suppression in electronic circuits
  • Waveform shaping
  • Switching operations
  • Reference elements in precision circuits

Quality and Reliability

Microchip Technology is known for its commitment to quality, and the 1N5226 Zener diode is no exception. It is manufactured to high standards to ensure consistent performance and reliability. Whether you are designing consumer electronics, industrial control systems, or automotive applications, the 1N5226 is a dependable choice for maintaining stable voltage levels within your electronic designs.

By incorporating the 1N5226 into your projects, you can trust in the stability and precision that Microchip Technology brings to the table, ensuring your applications run smoothly and efficiently.
