Products specifications

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Tube/Rail
Status Active
Memory Format EEPROM
Technology EEPROM
Memory Size 1Mb (128K x 8)
Max Frequency 400kHz
Access Time 900ns
Supply Voltage - Operating 2.5 V to 5.5 V
Temperature Range - Operating -40°C to 125°C (TA)
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 083504-24LC1025-E/SN
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 24LC1025-E/SN CAD Model

Description

Microchip Technology's 24LC1025-E/SN EEPROM

The 24LC1025-E/SN from Microchip Technology is a 1024 Kbit Electrically Erasable Programmable Read-Only Memory (EEPROM) device that provides a robust storage solution for advanced microcontroller-based systems. This high-density memory chip is designed to meet the rigorous demands of modern electronic applications, offering a reliable way to store configuration settings, calibration data, and application parameters that must be preserved when power is removed.

Key Features

  • Large Storage Capacity: With 1024 Kbits (or 128 Kbytes) of data storage, the 24LC1025-E/SN provides ample space for storing large amounts of data in a small package.
  • I2C Serial Interface: The device features a serial I2C interface, allowing for easy integration into most microcontroller-based systems with minimal pin count.
  • Low-power Consumption: Designed for power-sensitive applications, this EEPROM operates with very low power, helping to extend battery life in portable devices.
  • Wide Voltage Range: The 24LC1025-E/SN operates across a broad voltage range of 2.5V to 5.5V, making it suitable for a diverse set of applications and system designs.
  • High Reliability: With a high write endurance and data retention period, the EEPROM ensures data integrity and longevity, essential for mission-critical applications.
  • Page Write Buffer: The device supports page write operations, enabling faster data writing and efficient use of the I2C bus.

Applications

The versatility of the 24LC1025-E/SN makes it an ideal choice for a variety of applications, including:

  • Industrial and automotive control systems
  • Medical devices
  • Smart cards and identification systems
  • Consumer electronics
  • Telecommunication infrastructure

Package and Quality

The 24LC1025-E/SN comes in a practical 8-pin SOIC (SN) package, which is widely accepted in the industry and compatible with standard PCB layouts. Microchip Technology's commitment to quality ensures that this EEPROM device is manufactured to the highest standards, providing reliable performance for the lifetime of your product.

Whether you're designing a new system or upgrading an existing one, the 24LC1025-E/SN EEPROM from Microchip Technology is a smart choice for your non-volatile memory needs, offering durability, compatibility, and ease of use.
