The ATF1504AS-10JI68 is a high-performance, programmable logic device (PLD) from the reputable manufacturer Microchip Technology. This integrated circuit is part of the ATF1500A family of Complex Programmable Logic Devices (CPLDs) that offer a versatile solution for various digital logic applications. The device is designed to meet the needs of high-speed and high-density logic designs, providing a robust and flexible platform for hardware designers.

Key Features

• High-Density Design: With its 68-pin J-lead chip carrier (JLCC) package, the ATF1504AS-10JI68 provides a compact footprint while still offering a substantial amount of logic resources and I/O capabilities.
• Advanced Architecture: The device features a 5V, 10ns architecture, making it suitable for applications that require fast signal processing and high reliability in operation.
• Programmable Logic: The ATF1504AS-10JI68 contains 64 macrocells that can be configured to implement a wide range of logic functions, from simple gates to complex sequential circuits.
• Flexible I/O: It offers a versatile I/O structure that supports a variety of standards, ensuring compatibility with a broad range of digital systems.
• Reprogrammable: This CPLD is reprogrammable, which means it can be updated or modified to adapt to evolving design requirements, making it an ideal choice for prototyping and iterative development processes.

Applications

The ATF1504AS-10JI68 is suited for a wide array of applications, including but not limited to:

• Automotive systems
• Industrial control systems
• Telecommunications infrastructure
• Consumer electronics
• Data processing equipment

Technical Specifications

• Supply Voltage: 5V ±10%
• Operating Temperature: -40°C to +85°C
• Package Type: 68-pin JLCC
• Propagation Delay: 10ns
• I/O Pins: 34
• Macrocells: 64

With its robust set of features and Microchip Technology's reputation for quality, the ATF1504AS-10JI68 CPLD is an excellent choice for designers looking for a high-performance, programmable logic solution.
