Products specifications Report Issue?

Category Integrated Circuits (ICs)>Interface - Controllers
Mfr Microchip Technology
Package Tape & Reel (TR)
Protocol Ethernet
Function Controller
Interface SPI
Standards 10/100 Base-FX/T/TX PHY
Voltage - Supply 1.8V ~ 3.3V
Temperature Range - Operating 0°C ~ 70°C
Package / Case 64-VFQFN Exposed Pad
Supplier Device Package 64-QFN (9x9)
Base Product Number LAN9252
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN 3A991A2
HTSUS 8542.31.0001
Standard Package 3,000
Win Source Part Number 1001230-LAN9252T/ML
Ultra Librarian 3D Model Ultra Librarian LAN9252T/ML CAD Model

Description

Microchip Technology's LAN9252T/ML

The LAN9252T/ML is a high-performance, standalone EtherCAT controller from Microchip Technology, designed to address the demanding requirements of industrial automation and process control applications. With its rich feature set and robust design, it is engineered to facilitate the development of high-speed, deterministic communication in a wide range of industrial devices, such as sensors, actuators, and robotic systems.

Key Features:

  • Dual ARM Cortex-M4 Cores: The device is equipped with two ARM Cortex-M4 cores, providing ample processing power for managing complex tasks and protocols.
  • Integrated PHYs: The LAN9252T/ML includes dual integrated Ethernet PHYs, which simplifies the hardware design process by reducing external component requirements.
  • Flexible Interface Options: It offers a variety of interface options including SPI, SQI, and parallel interfaces, allowing for seamless integration with a wide range of host processors.
  • Real-Time Performance: Designed for real-time applications, it ensures low-latency communication and supports cycle times down to tens of microseconds.
  • Extended Temperature Range: The device is capable of operating in extreme industrial environments with a temperature range from -40°C to +85°C.
  • Comprehensive Development Support: Microchip provides extensive support for development, including software drivers, application examples, and a dedicated support team.

Applications:

The LAN9252T/ML is suited for various industrial applications such as:

  • Industrial Automation
  • Process Control Systems
  • Motion Control
  • Robotics
  • Industrial Internet of Things (IIoT) Devices

Overall, the LAN9252T/ML EtherCAT controller is a powerful solution that combines performance, integration, and reliability, making it a top choice for developers and engineers looking to leverage the speed and synchronization capabilities of EtherCAT technology in their industrial systems.
