Microchip Technology MIC2782DLYCS-TR

The MIC2782DLYCS-TR from Microchip Technology is a high-performance, dual-channel integrated circuit (IC) designed for a variety of applications where power management is critical. This IC features two independent push-button reset timers, making it an ideal solution for systems that require manual reset capability and precise timing control.

The MIC2782DLYCS-TR is designed to monitor push-button inputs, providing an easy and intuitive interface for users to reset electronic systems. Each channel can be configured for different timing settings, allowing for customization based on specific application requirements. The device is capable of generating a reset signal when the push-button is pressed and held for a user-configurable duration, which helps to prevent accidental resets due to brief button presses.

This product is packaged in a compact, 6-pin Thin SOT-23 package, making it suitable for space-constrained applications. It operates over a wide supply voltage range of 1.6V to 5.5V, ensuring compatibility with various low-voltage and standard logic level systems. The MIC2782DLYCS-TR also boasts a low quiescent current, contributing to energy efficiency and battery life extension in portable devices.

Key features of the MIC2782DLYCS-TR include:

• Two independently programmable channels
• User-configurable delay times for reset activation
• Wide operating voltage range (1.6V to 5.5V)
• Low quiescent current for power-sensitive applications
• High ESD protection (2 kV HBM)
• Debounced push-button inputs
• Compact 6-pin Thin SOT-23 package

Applications for the MIC2782DLYCS-TR are diverse and include but are not limited to:

• Portable electronic devices
• Consumer electronics
• Smart home devices
• Computing equipment
• Medical devices
• Industrial controls

The MIC2782DLYCS-TR is a reliable and versatile choice for designers and engineers looking to implement manual reset functionality with precision timing control. Its low power consumption and broad compatibility make it an excellent choice for a wide range of power management applications.
