Products specifications

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Tube/Rail
Status Active
Output Type Adjustable
Number of Regulators 1
Maximum Input Voltage 6V
Nominal Output Voltage (Min/Fixed) 1.24V
Maximum Output Voltage 6V
Dropout Voltage-Max 0.5V @ 1A
Output Current 1A
Operating Supply Current 25mA
Control Features Enable
Protection Features Over Current, Over Temperature
Temperature Range - Operating -40°C to 125°C
Regulator Topology Positive Adjustable
Output Voltage 1.24 V to 6 V
Voltage - Dropout (Typical) 0.28V @ 1A
Mounting SMD (SMT)
Case / Package S-PAK-5
Win Source Part Number 023276-MIC37102WR
Ultra Librarian 3D Model Ultra Librarian MIC37102WR CAD Model

Description

Product Overview: MIC37102WR LDO Voltage Regulator

The MIC37102WR from Microchip Technology is a high-performance, low-dropout (LDO) voltage regulator designed to deliver a continuous output current of 1A. This device is a perfect solution for applications requiring a regulated and stable voltage supply, while maintaining a low voltage differential between the input and output, which enhances power efficiency and thermal performance.

Key Features

  • Output Voltage: The MIC37102WR offers an adjustable output voltage range from 1.24V to 5.5V, making it versatile for a wide array of applications.
  • High Output Current: With its ability to supply up to 1A of output current, this regulator can power many standard devices and circuits.
  • Low Dropout: The low dropout voltage minimizes power loss and improves efficiency, making it ideal for battery-powered devices.
  • Stability: It is stable with ceramic output capacitors, ensuring reliable performance and simplifying design considerations.
  • Protection Features: The MIC37102WR includes over-current protection and thermal shutdown to safeguard the device and the system under extreme conditions.
  • Wide Input Voltage Range: The regulator operates over a broad input voltage range from 2.25V to 6V, accommodating various power sources.
  • Fast Transient Response: It is capable of maintaining a stable output voltage despite rapid changes in load, which is critical for sensitive electronics.

Applications

The MIC37102WR is suitable for numerous applications, including but not limited to:

  • Portable and battery-operated devices
  • Microprocessor/microcontroller power supplies
  • Digital cameras and video equipment
  • Peripheral cards
  • Wireless communication devices

Package and Quality

Encased in a robust TO-263 (D2PAK) package, the MIC37102WR is designed to withstand harsh environments and is capable of handling high levels of thermal stress. Microchip Technology's commitment to quality ensures that this LDO voltage regulator delivers consistent performance and reliability.

For detailed specifications, application notes, and additional resources, designers and engineers are encouraged to consult the official Microchip Technology datasheets and product documentation.
