Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Tube
Output Type Adjustable
Voltage - Input (Maximum) 24V
Min/Fixed Output Voltage 1.24V
Maximum Output Voltage 20V
Maximum Dropout Voltage 0.5V at 150mA
Output Current 150mA
Current - Quiescent (Iq) 35μA
Maximum Supply Current 4mA
PSRR 50dB (1kHz)
Control Features Enable
Protection Features Over Current, Over Temperature, Reverse Polarity
Temperature Range - Operating -40°C ~ 125°C
Mounting Style SMD
Manufacturer Package TO-252-6, DPak (5 Leads + Tab)
Supplier Device Package TO-252-5
Family Part Number MIC5295
Manufacturer Pack Quantity 80
MSL Level 3 (168 Hours)
Win Source Part Number 1222938-MIC5295YD
Manufacturer Homepage www.micrel.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MIC5295YD CAD Model

Description

MIC5295YD: Low-Dropout Voltage Regulator from Microchip Technology

The MIC5295YD is a high-performance, low-dropout (LDO) voltage regulator from Microchip Technology, designed to provide a stable and reliable power supply for a wide range of applications. This efficient regulator is capable of delivering up to 150mA of continuous output current, making it an ideal choice for portable devices, microcontrollers, and other sensitive electronic equipment.

With an impressive dropout voltage of typically just 180mV at full load, the MIC5295YD ensures minimal power loss and helps extend battery life in portable applications. The regulator operates over a wide input voltage range from 2.5V to 10V, providing the flexibility needed to support various system architectures and battery chemistries.

One of the key features of the MIC5295YD is its fast transient response, which is critical for maintaining output voltage stability during sudden changes in load. This characteristic is particularly important for powering CPUs, FPGAs, and other digital ICs that can exhibit rapid swings in power consumption.

The MIC5295YD also incorporates several protection features to safeguard your application, including over-current protection and thermal shutdown. These protective measures ensure that the regulator and your application remain safe under abnormal operating conditions.

Designed for ease of use, the MIC5295YD requires minimal external components, which can help reduce overall design complexity and system cost. It is available in a small, surface-mountable SOT-23-5 package, which is suitable for space-constrained applications.

Additional features of the MIC5295YD include:

  • Low noise performance, making it suitable for RF and precision analog circuits.
  • High PSRR (Power Supply Rejection Ratio) which enhances stability and performance under fluctuating input voltage conditions.
  • Stable with low-ESR ceramic capacitors, which reduces the size and cost of the external components.
  • Zero off-mode current which helps to maximize battery life for portable applications.

Overall, the MIC5295YD from Microchip Technology is a robust, versatile LDO voltage regulator that offers high performance, reliability, and design flexibility, making it an excellent choice for a broad array of electronic applications.
