Win Source Part Number WS1203199-PAC1944T-E/4MX
Manufacturer Microchip Technology
Category Integrated Circuits (ICs) Power Management (PMIC) Current Regulation/Management
Package Tape & Reel (TR) Cut Tape (CT)
Product Status Active
Function Current/Voltage Monitor
Voltage - Input 2.7V ~ 5.5V
Operating Temperature -40°C ~ 125°C (TA)
Mounting Type Surface Mount, Wettable Flank
Package / Case 16-VFQFN Exposed Pad
Supplier Device Package 16-VQFN (3x3)
Ultra Librarian 3D Model Ultra Librarian PAC1944T-E/4MX CAD Model

Description

Introducing the PAC1944T-E/4MX from Microchip Technology

The PAC1944T-E/4MX is a remarkable piece of technology from Microchip Technology, designed to cater to the advanced needs of power monitoring and measurement in various electronic applications. This high-precision device is a testament to Microchip's commitment to providing innovative solutions for power management challenges.

Key Features:

  • High Accuracy: With the PAC1944T-E/4MX, users can expect high-precision measurements, thanks to its integrated full-duplex, bi-directional current-sensing capabilities.
  • Multi-Channel Integration: The device features four independent measurement channels, allowing for simultaneous monitoring of voltage, current, and power on multiple rails.
  • Wide Voltage Range: It is capable of monitoring supply voltages ranging from 0V to 32V, making it incredibly versatile for various applications.
  • High-Resolution ADC: The onboard 14-bit analog-to-digital converter ensures that the measurements are not only precise but also have a high degree of resolution.
  • Configurable Averaging: The PAC1944T-E/4MX offers configurable averaging, which means that it can adapt to different signal noise environments for optimal performance.
  • Easy Integration: Its I2C-compatible interface allows for seamless integration with most microcontroller-based systems.

Applications:

The PAC1944T-E/4MX is ideally suited for a wide range of applications, including but not limited to:

  • Power supply monitoring
  • Battery management systems
  • Server and telecom power supplies
  • Embedded computing systems
  • Energy management systems

Technical Specifications:

Microchip's PAC1944T-E/4MX offers a compact, yet powerful solution for real-time power measurement. The technical specifications include an operating temperature range from -40°C to +125°C, which ensures reliability across various environmental conditions. Moreover, the small form factor of the device makes it an ideal choice for space-constrained applications.

In summary, the PAC1944T-E/4MX from Microchip Technology is a state-of-the-art power monitoring IC that provides designers and engineers with the tools they need to accurately measure power consumption in their systems, ensuring efficiency and reliability in their electronic designs.
