Products specifications Report Issue?

Category Integrated Circuits (ICs) - Embedded - Microcontrollers
Mfr Microchip Technology
Series PIC® 16F
Package Tube
Product Status Active
Core Processor PIC
Core Size 8-Bit
Speed 32MHz
Connectivity I²C, LINbus, SPI, UART/USART
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Number of I/O 35
Program Memory Size 7KB (7K x 8)
Program Memory Type FLASH
EEPROM Size -
RAM Size 512 x 8
Voltage - Supply (Vcc/Vdd) 1.8V ~ 5.5V
Data Converters A/D 28/2x10b
Oscillator Type Internal
Temperature Range - Operating -40°C ~ 125°C (TA)
Mounting Type Surface Mount
Package / Case 40-VFQFN Exposed Pad
Supplier Device Package 40-QFN (5x5)
Base Product Number PIC16F15274
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN 3A991A2
HTSUS 8542.31.0001
Win Source Part Number 1356584-PIC16F15274-E/MP
Ultra Librarian 3D Model Ultra Librarian PIC16F15274-E/MP CAD Model

Description

Microchip Technology's PIC16F15274-E/MP Microcontroller

The PIC16F15274-E/MP from Microchip Technology is a versatile and powerful 8-bit microcontroller that is an ideal choice for a variety of applications. This robust microcontroller is part of the PIC16F family, which is renowned for its ease of use, low power consumption, and advanced peripherals. Designed to operate under extended temperatures, the PIC16F15274-E/MP is suitable for industrial and automotive applications that demand reliable performance in harsh conditions.

Key Features

  • CPU: Enhanced Mid-range Core with 49 Instruction, 16 Stack Levels
  • Memory: 28KB Flash Program Memory, 2KB RAM, 256 Bytes EEPROM
  • Speed: Up to 32 MHz internal oscillator
  • I/O Pins: 35 General Purpose I/O pins with interrupt-on-change
  • Communication Peripherals: Two UART modules, Two SPI modules, Two I2C modules
  • Analog Features: 28-channel 10-bit Analog-to-Digital Converter (ADC), 5-bit Digital-to-Analog Converter (DAC)
  • Timers: Four Timer Modules (Two 8-bit, Two 16-bit)
  • Additional Peripherals: Two CCP (Capture/Compare/PWM), Two 16-bit PWMs, Complementary Waveform Generator (CWG)
  • Operating Voltage Range: 1.8V to 5.5V
  • Temperature Range: -40°C to +125°C
  • Packaging: 64-Pin QFN

With its extensive memory resources, the PIC16F15274-E/MP is capable of supporting complex applications and can be programmed with Microchip's MPLAB® X Integrated Development Environment (IDE) and MPLAB Code Configurator for streamlined development. The integrated ADC and DAC provide excellent analog capabilities, allowing for precise sensor interfacing and control tasks.

For connectivity, the inclusion of multiple UART, SPI, and I2C modules enable the PIC16F15274-E/MP to communicate with other microcontrollers, sensors, and peripherals, making it a great choice for embedded systems that require robust serial communications.

The combination of high-performance features, extended temperature range, and the reliability of Microchip Technology makes the PIC16F15274-E/MP a smart choice for designers looking to create sophisticated and durable electronic products.
