Products specifications Report Issue?

Category Integrated Circuits (ICs) - Embedded - Microcontrollers
Mfr Microchip Technology
Series PIC® XLP™ mTouch™ 16F
Package Tube
Product Status Active
Programmable Not Verified
Core Processor PIC
Core Size 8-Bit
Speed 32MHz
Connectivity I2C, LINbus, SPI, UART/USART
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Number of I/O 17
Program Memory Size 14KB (8K x 14)
Program Memory Type FLASH
EEPROM Size 256 x 8
RAM Size 1K x 8
Voltage - Supply (Vcc/Vdd) 1.8V ~ 5.5V
Data Converters A/D 12x10b
Oscillator Type Internal
Temperature Range - Operating -40°C ~ 125°C (TA)
Mounting Type Through Hole
Package / Case 20-DIP (0.300", 7.62mm)
Supplier Device Package 20-PDIP
Base Product Number PIC16F1829
Standard Package 22 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN 3A991A2
HTSUS 8542.31.0001
Win Source Part Number 655244-PIC16F1829-E/P
Ultra Librarian 3D Model Ultra Librarian PIC16F1829-E/P CAD Model

Description

Product Overview: PIC16F1829-E/P by Microchip Technology

The PIC16F1829-E/P is a high-performance microcontroller unit (MCU) from Microchip Technology, designed for embedded applications requiring a rich feature set and high levels of integration. This MCU is part of Microchip's enhanced mid-range core product line, offering increased computational performance alongside a diverse set of peripherals.

Key Features:

  • Core: The device is built on a PIC architecture with a CPU running at a maximum frequency of 32 MHz, providing a perfect balance between power consumption and processing capability.
  • Memory: It boasts 3.5 KB of RAM and 14 KB of flash memory, providing ample space for application code and data storage.
  • I/O Pins: The PIC16F1829-E/P comes with 25 I/O pins, allowing for versatile interfacing with sensors, actuators, and other peripherals.
  • Communication Peripherals: Integrated communication modules include I2C, SPI, and USART, facilitating easy data exchange with other devices and systems.
  • 10-bit Analog-to-Digital Converter (ADC): The onboard ADC with up to 17 channels enables the MCU to process analog signals, making it ideal for sensor-based applications.
  • PWM Modules: Enhanced Capture/Compare/PWM (ECCP) modules allow for precise control over motor functions and other time-critical tasks.
  • Timers: Multiple timers support a range of timing and counting functions, contributing to the device's versatility in various applications.

Applications:

The PIC16F1829-E/P is suited for a wide array of applications, including but not limited to consumer electronics, automotive systems, industrial automation, and IoT devices. Its robust feature set and adaptability ensure that it can meet the demands of complex and varied tasks.

Package and Quality:

Housed in a PDIP (Plastic Dual In-line Package), the PIC16F1829-E/P ensures ease of prototyping and integration into various circuit designs. Microchip Technology is known for its commitment to quality, and this product is no exception, offering reliability and performance in a compact form factor.
