PIC16F1829-I/SO

Name: PIC16F1829-I/SO
Brand: Microchip Technology
SKU: 655245
Availability: InStock
Rating: 5 (248 reviews)

Part No	PIC16F1829-I/SO
Manufacturer	Microchip Technology
Catalog	Electrical Parts
Description	14/20-Pin Flash Microcontrollers with nanoWatt XLP Technology
Datasheet	PIC16F1829-I/SO Datasheet
Sample
ECAD Module

	New List Existing List This product has been added to your List. List Name:

Shipping Information

Shipped from	HK warehouse
Expected Shipping Date	Ship today if order in (HKT)
Supplier Lead-Time	Call for availability
Estimate shipping fee	Enter your destination to get a shipping estimate Estimate Shipping Fee

Pricing & Ordering $2.8494

Quantity

Unit Price

Ext. Price

14+

$3.6740

$51.436

34+

$3.0150

$102.510

52+

$2.9210

$151.892

71+

$2.8270

$200.717

92+

$2.7320

$251.344

123+

$2.4500

$301.350

* The above prices does not include taxes and freight rates, which will be calculated on the order pages.

Availability: 58,376 pieces

MOQ: 14 pcs

Order Increment : 1 pcs

Qty:

*Need More Quantity? *Request a Bulk Quantity Quotation?

Products specifications

Categories	Integrated Circuits (ICs)
Manufacturer	Microchip Technology
Series	PIC XLP mTouch 16F
Packaging	Tube
Core Processor	PIC
Core Size	8-Bit
Speed	32MHz
Connectivity	I2C, LIN, SPI, UART/USART
Peripherals	Brown-out Detect/Reset, POR, PWM, WDT
Number of I/O	17
Program Memory Size	14KB (8K x 14)
Program Memory Type	FLASH
EEPROM Size	256 x 8
RAM Size	1K x 8
Supply Voltage	1.8 V ~ 5.5 V
Data Converters	A/D 12x10b
Oscillator Type	Internal
Operating Temperature Range	-40°C ~ 85°C (TA)
Package	20-SOIC (0.295", 7.50mm Width)
Manufacturer Package	20-SOIC
Win Source Part Number	1237933-PIC16F1829-I/SO
Manufacturer Homepage	www.microchip.com
Family Name	PIC16F1829
Introduction Date	August 30, 2010
ECCN	EAR99
Country of Origin	Thailand
Halogen Free	Compliant
Estimated EOL Date	2023
Is this a common-used part?	Yes
Popularity	High
Fake Threat In the Open Market	52 pct.
Supply and Demand Status	Balance
Alternative Parts (Cross-Reference)	CY7C63001A-SC; CY7C63001A-SXC; CY7C63001C-SXCT;

Description

Product Overview: PIC16F1829-I/SO

The PIC16F1829-I/SO is a high-performance microcontroller unit (MCU) from the renowned manufacturer Microchip Technology. This device is part of the PIC16F family, which is well-known for its versatility and efficiency in handling a wide range of embedded applications. The PIC16F1829-I/SO comes in a 28-pin SOIC package, which is suitable for surface-mount technology (SMT) and offers a compact footprint for space-constrained applications.

At the heart of the PIC16F1829-I/SO is an 8-bit processor with an enhanced Mid-range core. The MCU operates at a speed of up to 32 MHz and features an internal oscillator, which reduces the need for external components. With 14 KB of flash memory and 1 KB of RAM, this microcontroller provides ample space for application code and data storage, making it an ideal choice for a variety of complex tasks.

The device boasts a rich set of peripherals, including:

10-bit Analog-to-Digital Converter (ADC) with up to 17 channels
Two comparators
Two Pulse Width Modulation (PWM) modules
Enhanced Universal Synchronous Asynchronous Receiver Transmitter (EUSART)
Two Capture, Compare, PWM (CCP) modules

These peripherals enable the PIC16F1829-I/SO to handle complex tasks such as sensor interfacing, motor control, and communication with other devices. The microcontroller also features various serial communication interfaces, including I²C, SPI, and EUSART, which allow for easy integration into a broader system and communication with other ICs.

For enhanced safety and reliability, the PIC16F1829-I/SO includes Power-on Reset (POR), Power-up Timer (PWRT), Oscillator Start-up Timer (OST), and Brown-out Reset (BOR). It also supports in-circuit serial programming (ICSP) and in-circuit debugging (ICD) features, which facilitate easy development and troubleshooting.

In summary, the PIC16F1829-I/SO from Microchip Technology is a powerful and versatile MCU that is well-suited for a wide range of applications, from industrial control systems to consumer electronics. Its extensive feature set and ease of use make it a top choice for designers looking for a reliable and cost-effective solution for their embedded projects.
