Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Estimated Pruduction Lead Time 51 Weeks
Features series Microcontroller IC
Manufacturer Microchip Technology
Series PIC® 18F
Package Tube
Number of I/O 25
Family Name PIC18F2520
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN 3A991A2
HTSUS 8542.31.0001
Quantity per package 27
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 846568-PIC18F2520-E/SO
Ultra Librarian 3D Model Ultra Librarian PIC18F2520-E/SO CAD Model

Description

Product Overview: PIC18F2520-E/SO from Microchip Technology

The PIC18F2520-E/SO is a high-performance microcontroller designed by Microchip Technology, a leading provider of smart, connected, and secure embedded control solutions. This particular model is part of the PIC18F family, which is renowned for its advanced features and capabilities that cater to a wide range of applications, from automotive systems to consumer electronics.

Key Features

  • Core: The microcontroller is built on a powerful PIC18 core with a maximum CPU speed of 40 MHz, providing robust processing capabilities for complex applications.
  • Memory: It comes equipped with 32KB of flash program memory, 1536 bytes of RAM, and 256 bytes of EEPROM, ensuring ample space for code and data storage.
  • I/O Pins: The device includes 25 programmable I/O pins, which allows for versatile interfacing with various peripherals and devices.
  • Communication Peripherals: It supports multiple communication protocols such as USART, SPI, and I2C, enabling easy integration with other components and systems.
  • 10-bit ADC: An integrated 10-bit Analog-to-Digital Converter with up to 13 channels allows for precise sensor readings and analog data acquisition.
  • Timers: The microcontroller features one 8-bit and three 16-bit timers, providing accurate timing and measurement capabilities.
  • Operating Voltage: The operating voltage range of 2.0V to 5.5V makes it suitable for both low-power and standard applications.
  • Temperature Range: With an industrial temperature range from -40°C to +85°C, it ensures reliable operation under extreme conditions.
  • Packaging: The PIC18F2520-E/SO comes in a 28-pin SOIC package, which is ideal for space-constrained applications.

Applications

The versatility of the PIC18F2520-E/SO allows it to be used in a multitude of applications including but not limited to:

  • Automotive systems
  • Industrial control systems
  • Consumer electronics
  • Medical devices
  • Home automation
  • Communication systems

Overall, the PIC18F2520-E/SO microcontroller from Microchip Technology is a robust and versatile solution for designers and engineers looking to develop advanced and reliable embedded systems.
