The SCH3114I-NU from Microchip Technology is a versatile Super I/O controller designed to support the varied needs of embedded systems. This high-performance chip incorporates a range of I/O functions, making it an ideal solution for motherboard applications in desktops, servers, and industrial PCs.

Key Features

• Multiple Interfaces: The device includes a variety of interfaces such as floppy disk controller, keyboard controller, mouse controller, and multiple serial/parallel ports, ensuring comprehensive connectivity options for peripheral devices.
• Enhanced Power Management: It is equipped with advanced power management capabilities that help reduce overall system power consumption and support green computing initiatives.
• High Integration: The SCH3114I-NU integrates hardware monitoring functions, including temperature and voltage monitoring, which are crucial for maintaining system stability and performance.
• Flexible Configuration: The device offers configurable I/O address and IRQ settings, allowing for seamless integration into various system architectures without hardware conflicts.

Applications

The SCH3114I-NU is suitable for a wide range of applications, including:

• Industrial automation and control systems
• Embedded systems
• Point-of-sale terminals
• Networking equipment
• Server motherboards

Technical Specifications

Attribute Description Package / Case 128-QFP Operating Temperature -40°C to +85°C Supply Voltage 3.3V Interface Type Serial, Parallel

With its robust feature set and Microchip's commitment to reliability, the SCH3114I-NU Super I/O controller is a smart choice for designers looking to enhance their system's I/O capabilities while maintaining a high level of integration and efficiency.
