The SST39VF200A-70-4C-M1QE-T from Microchip Technology is a high-performance, reliable, and versatile CMOS Multi-Purpose Flash (MPF) memory integrated circuit. Designed to meet the rigorous demands of modern electronics, this device offers a fast read and write capability, making it an ideal choice for a wide range of applications including embedded systems, telecommunications, digital consumer electronics, and automotive electronics.

Key Features

• Memory Size: The device boasts a storage capacity of 2 Mbit, which is organized as 256K x 8 (byte mode) or 128K x 16 (word mode), providing ample space for firmware storage, boot code, or data logging.
• Access Time: With a fast access time of 70 ns, the SST39VF200A ensures quick data retrieval, contributing to the overall system performance and responsiveness.
• Operating Voltage: It operates within a voltage range of 2.7V to 3.6V, making it compatible with low-voltage applications and contributing to power efficiency.
• Endurance: The device is built for longevity, offering a minimum of 100,000 erase and program cycles per sector, ensuring data integrity and reliability over an extended period.
• Temperature Range: This flash memory is designed to operate over an industrial temperature range of -40°C to +85°C, ensuring stable performance under extreme conditions.
• Programming and Erase Times: The SST39VF200A features a sector-erase time of 18 ms typical and a chip-erase time of 70 ms typical, with a byte- or word-program time of 14 μs typical. This allows for efficient updates and changes to stored data.
• Package: The device comes in a TSOP-48 package, which is suitable for surface mount technology and occupies minimal board space.

Applications

The versatility of the SST39VF200A-70-4C-M1QE-T allows it to be used in a variety of applications. Its robust design is suited for mission-critical systems where data integrity and device reliability are paramount. Its use cases include but are not limited to boot memory for computers and servers, storage for configuration parameters in network devices, firmware storage for consumer electronics, and code storage in automotive electronics.

Overall, the SST39VF200A-70-4C-M1QE-T from Microchip Technology represents a perfect blend of performance, durability, and compactness, making it a top choice for designers and engineers seeking a reliable non-volatile memory solution.
