HAL505UA-A Micronas GmbH
Same model may have multiple batches, images only for reference.

HAL505UA-A

Part No HAL505UA-A
Manufacturer Micronas GmbH
Catalog Magnetic Sensors - Switches (Solid State)
Description MAGNETIC SWITCH LATCH TO92-3 / Hall-Effect Sensor Family
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer TDK-Micronas GmbH
Packaging Tape & Box (TB)
Part Status Last Time Buy
Function Latch
Technology Hall Effect
Polarization South Pole
Sensing Range 17mT Trip, -17mT Release
Test Condition 25°C
Supply Voltage (V) 3.8V ~ 24V
Current - Supply (Maximum) 4.2mA
Current - Output (Maximum) 20mA
Output Type Open Drain
Features Temperature Compensated
Temperature Range - Operating -40°C ~ 170°C
Manufacturer Package TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Supplier Device Package TO-92-3
Manufacturer Pack Quantity 2,000
MSL Level 1 (Unlimited)
Popularity Medium
Supply and Demand Status Balance
Win Source Part Number 803284-HAL505UA-A
Ultra Librarian 3D Model Ultra Librarian HAL505UA-A CAD Model

Description

The HAL505UA-A is a temperature compensated Hall effect sensor with an output type of open drain.

  • Sensing Range: 17mT Trip, -17mT Release
  • Polarization: South Pole
  • Latch Function: Yes
  • Current Output (maximum): 20mA
  • Technology: Hall effect
  • Test Condition: 25°C
  • Package: TO-92-3
  • Supply Voltage Range: 3.8V to 24V
  • Current Supply (maximum): 4.2mA
