SG1825CJ-DESC Microsemi Corporation
Same model may have multiple batches, images only for reference.

SG1825CJ-DESC

Part No SG1825CJ-DESC
Manufacturer Microsemi Corporation
Catalog PMIC - Voltage Regulators - DC DC Switching Controllers
Description IC REG CTRLR BUCK/FLYBACK 16DIP
Datasheet
SG1825CJ-DESC Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Microsemi Corporation
Series Military, MIL-STD-883B
Packaging Tube
Output Type Transistor Driver
Function Step-Down, Step-Up/Step-Down
Output Configuration Positive
Topology Buck, Flyback
Number of Outputs 2
Output Phases 1
Supply Voltage 10 V ~ 30 V
Frequency - Switching 4kHz ~ 1.5MHz
Duty Cycle (Maximum) 85%
Synchronous Rectifier Yes
Clock Sync No
Control Features Current Limit, Ramp, Soft Start
Operating Temperature Range -55°C ~ 125°C (TA)
Manufacturer Package 16-CDIP
Win Source Part Number 764148-SG1825CJ-DESC
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian SG1825CJ-DESC CAD Model

Description

The Microsemi Corporation SG1825CJ-DESC is a military-grade step-down and step-up/step-down transistor driver integrated circuit.

  • Temperature Range: -55°C to 125°C (TA)
  • Frequency-Switching Range: 4kHz to 1.5MHz
  • Control Features: Current Limit, Ramp, Soft Start
  • Supply Voltage: 10 V to 30 V
  • Package: 16-CDIP
  • Duty Cycle: 85%
  • Supply and Demand: Limited
