8301-2-24-80-00-00-01-0

Part No 8301-2-24-80-00-00-01-0
Manufacturer Mill-Max Manufacturing Corp.
Catalog Terminals - PC Pin, Single Post Connectors
Description CONN PC PIN
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Terminal Type PC Pin
Terminal Style Wire
Pin Size - Above Flange 0.025" (0.64mm) Square
Length - Above Flange 0.532" (13.51mm)
Length - Below Flange 0.158" (4.01mm)
Length - Overall 0.690" (17.53mm)
Mounting Hole Diameter 0.057" (1.45mm)
Mounting Type Through Hole
Termination Press-Fit, Knurled, Wire Wrap
Insulation Non-Insulated
Contact Material Brass Alloy
Contact Finish Tin
Contact Finish Thickness 200.0µin (5.08µm)
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1630045-8301-2-24-80-00-00-01-0
Ultra Librarian 3D Model Ultra Librarian 8301-2-24-80-00-00-01-0 CAD Model
