The Molex 1051330011 is a USB Type-C Receptacle. This connector is designed to provide a versatile and robust connection for various USB applications, supporting data transfer, power delivery, and display connectivity. The Type-C connector's reversible design and high bandwidth capabilities make it ideal for modern electronic devices.

Applications:

• Smartphones
• Tablets
• Laptops
• External Hard Drives
• Docking Stations
• Power Adapters

Features:

• USB Type-C Connector
• Reversible Plug Orientation
• Surface Mount Termination
• High Data Transfer Rates (USB 3.1 Gen 2 or higher, depending on implementation)
• Power Delivery (PD) Support
• Durable Construction

Benefits:

• Versatile Connectivity: Supports data transfer, power delivery, and display connectivity through a single connector.
• User-Friendly Design: The reversible plug orientation eliminates the need to worry about which way the connector is inserted.
• Fast Data Transfer: Supports high data transfer rates, enabling quick and efficient file transfers.
• Power Delivery: Supports power delivery, allowing devices to be charged quickly and efficiently.
• Compact Size: The small form factor makes it ideal for use in portable electronic devices.

Additional Details:

The 1051330011 is typically a surface mount connector designed for automated assembly. It supports USB 3.1 Gen 2 or higher data transfer rates, contingent on the design and implementation within the device. It is also often designed to support USB Power Delivery (USB PD), enabling it to handle higher power levels for charging laptops and other power-hungry devices. Consult the Molex datasheet for specific current and voltage ratings, mating information, PCB layout recommendations, and reflow soldering profile details.

Proper PCB design and soldering techniques are crucial for ensuring a reliable connection and optimal performance. Refer to the Molex documentation for detailed guidelines on these aspects.
