Same model may have multiple batches, images only for reference.
15-91-2080 Real Image
Same model may have multiple batches, images only for reference.

15-91-2080

Part No 15-91-2080
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn Unshrouded Header HDR 8 POS 2.54mm Solder ST SMD C-Grid Tube
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Connector Type PCB
Contact Material Bronze
Contact Plating Tin
Country of Origin US
Current Rating 3 A
ELV Compliant
Flammability Rating UL94 V-0
Gender Male
Glow Wire Compliant Non-compliant
Halogen Free Low Halogen
Housing Color Black
Housing Material Thermoplastic
Lead Free Yes
Lead Pitch 2.54 mm
Material Bronze
Maximum Operating Temperature 105 °C
Max Voltage Rating (DC) 250.25 kV
Min Operating Temperature -40 °C
Mount Surface Mount
Number of Circuits 8
Number of Contacts 8
Number of Positions 8
Number of Rows 2
Orientation Vertical, Right Angle
Pitch 2.54 mm
Plating Tin
REACH SVHC Unknown
RoHS Compliant
Termination SMD/SMT
Voltage Rating 250 V
Voltage Rating (DC) 250 V
Win Source Part Number 1034845-15-91-2080
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 15-91-2080 CAD Model

Description

This Molex product has the Win Source Part Number 1034845-15-91-2080. This Molex 1034845-15-91-2080 is a PCB connector.

  • Win Source Part Number: 1034845-15-91-2080
  • Connector Type: PCB
  • Positions: 8
  • Pitch: 2.54 mm
  • Gender: male
  • Rows: 2
  • Termination: SMD/SMT
  • Contact Material: bronze
  • Voltage Rating: 250 V
  • Current Rating: 3 A
  • Housing Material: thermoplastic
  • Contacts: 8
  • Circuits: 8
  • Orientation: vertical, right angle
  • Contact Plating: tin
  • Housing Color: black
  • RoHS Compliant: Yes
  • Low Halogen: Yes
