22283280 Real Image
Same model may have multiple batches, images only for reference.

22283280

Part No 22283280
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description KK 254 Breakaway Header, Vertical, with Polarizing Wall, 28 Circuits, Tin (Sn) Plating
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Black
Connector Type Male Pin
Contact Material Brass
Contact Mating Length 7.493 mm
Contact Plating Tin
Country of Origin US
Current Rating 4 A
Depth 7.21 mm
Gender Male
Housing Color Black
Housing Material Nylon
Length 71.12 mm
Max Operating Temperature 75 °C
Min Operating Temperature 0 °C
Mount Through Hole
Number of Circuits 27
Number of Contacts 28
Number of Positions 28
Number of Rows 1
Orientation Vertical
Packaging Bulk
Pitch 2.54 mm
Plating Tin
RoHS Compliant
Termination Solder
Win Source Part Number 1124020-22283280
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 22283280 CAD Model

Description

The Molex, LLC 1124020-22283280 is a black male pin connector with a pitch of 2.54mm and 28 number of positions.

  • Pitch: 2.54mm
  • Number of Positions: 28
  • Current Rating: 4A
  • Temperature Range: 0 °C ~ 75 °C
  • Supply and Demand Status: limited
