47420-0001 Real Image
Same model may have multiple batches, images only for reference.

47420-0001

Part No 47420-0001
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description 2.00mm Pitch Battery Connector, Surface Mount, Contact Width 0.70mm, 4 Circuits
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Contact Material Copper
Contact Plating Gold
Country of Origin HK
Current Rating 1 A
Glow Wire Compliant Non-compliant
Halogen Free Low Halogen
Housing Material Thermoplastic
Mount Surface Mount
Number of Circuits 4
Number of Positions 4
Number of Rows 1
Orientation Vertical
Packaging Tape & Reel
Pitch 2 mm
Plating Gold
REACH SVHC No SVHC
RoHS Compliant
Termination Solder
Win Source Part Number 1195197-47420-0001
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 47420-0001 CAD Model

Description

The 47420-0001 is a 4-position vertical surface mount circular connector housing manufactured by Molex, LLC.

  • Number of Positions: 4
  • Mounting Type: Vertical Surface Mount
  • Maximum Current: 1A
  • Pitch: 2mm
  • Package: Tape and Reel
  • Contact Plating: Gold
