502585-0570 Real Image
Same model may have multiple batches, images only for reference.

502585-0570

Part No 502585-0570
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn IDC Connector RCP 5 POS 1.5mm IDT ST Cable Mount Bag/Box
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Beige
Connector Type Center Strip Contact, Receptacle
Contact Gender Female
Contact Material Nickel, Tin
Contact Plating Tin
Contact Resistance 20 mΩ
Country of Origin JP
Current Rating 2 A
Depth 7.3 mm
Fastening Type Latch
Gender Receptacle
Glow Wire Compliant Non-compliant
Height 6.6 mm
Housing Color Beige
Housing Material Resin
Length 11.8 mm
Maximum Operating Temperature 85 °C
Min Operating Temperature -40 °C
Mount Surface Mount
Number of Circuits 5
Number of Contacts 5
Number of Pins 5
Number of Positions 5
Number of Rows 1
Orientation Right Angle
Packaging Tape & Reel
Pitch 1.5 mm
Radiation Hardening No
REACH SVHC No SVHC
RoHS Compliant
Termination Solder
Voltage Rating 100 V
Win Source Part Number 1038964-502585-0570
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 502585-0570 CAD Model

Description

The Molex 1038964-502585-0570 is a low-popularity electronic component that is in short supply.

  • Popularity: Low
  • Supply: Short Supply
  • Positions: 5
  • Pitch: 1.5 mm
  • Component Type: Connector
  • Features: Center Strip Contact, Receptacle Connector
