The Molex 52207-2485 is a SlimStack fine-pitch SMT (Surface Mount Technology) connector. Part of the SlimStack series, it's designed for applications demanding high density and space saving, typically found in portable devices and other compact electronic systems. The connector is a board-to-board type and is known for its secure mating and reliable electrical performance.

Applications:

• Smartphones and Tablets: Used for connecting internal components in these space-constrained devices.
• Laptop Computers: Employed for board-to-board connections within the laptop chassis.
• Digital Cameras: Utilized for connecting image sensors, displays, and other internal modules.
• Wearable Devices: Found in smartwatches, fitness trackers, and other wearable electronics.
• Medical Devices: Used in portable medical equipment where space is a premium.

Features:

• SlimStack Series: Designed for high-density board-to-board connections.
• 24 Circuits: Accommodates up to 24 individual circuits or signals.
• Fine Pitch: Features a very small pitch (typically 0.4mm or 0.5mm) for space saving.
• SMT Mounting: Designed for surface mount soldering onto printed circuit boards.
• Secure Mating: Provides a reliable and secure electrical connection.

Benefits:

• Space Saving: Enables compact designs due to its fine pitch and low profile.
• High Density: Allows for a large number of connections in a small area.
• Reliable Performance: Ensures stable and dependable electrical connections.
• Easy Assembly: Designed for automated SMT assembly processes.
• Versatile Applications: Suitable for a wide range of applications requiring high-density connections.

Technical Specifications:

Key specifications for the Molex 52207-2485 connector include:

• Number of Circuits: 24
• Series: SlimStack
• Pitch: Typically 0.4mm or 0.5mm (consult datasheet for exact value)
• Mounting Style: Surface Mount Technology (SMT)
• Material: Typically high-temperature plastic suitable for reflow soldering.
• Color: Varies (often black or beige)
• Operating Temperature Range: Typically -40°C to +85°C
• Mating Height: Very low profile, typically less than 1mm.

Consult the Molex datasheet for complete and accurate specifications.
