53047-0710 Real Image
Same model may have multiple batches, images only for reference.

53047-0710

Part No 53047-0710
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description 1.25mm (.049") Pitch PicoBlade Wire-to-Board Header, Vertical, with Friction Lock, 7 Circuits
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Body Plating Tin
Color Natural
Contact Gender Male
Contact Material Tin
Contact Plating Tin
Contact Resistance 20 mΩ
Country of Origin TW
Current Rating 1 A
Depth 7.3 mm
Flammability Rating UL94 V-0
Gender Male
Glow Wire Compliant Non-compliant
Height 4.2 mm
Housing Color Natural
Housing Material Polyamide
Insulation Resistance 100 MΩ
Lead Free Lead Free
Lead Pitch 1.25 mm
Length 14 mm
Max Operating Temperature 85 °C
Max Voltage Rating (AC) 125 V
Min Operating Temperature -40 °C
Mount Through Hole
Number of Circuits 7
Number of Contacts 7
Number of Pins 7
Number of Poles 7
Number of Positions 7
Number of Rows 1
Orientation Vertical
Pitch 1.25 mm
Plating Tin
Radiation Hardening No
REACH SVHC No SVHC
RoHS Compliant
Termination Solder
Voltage Rating 125 V
Voltage Rating (AC) 125 V
Voltage Rating (DC) 125 V
Working Voltage 125 V
Win Source Part Number 1129658-53047-0710
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 53047-0710 CAD Model

Description

The 1129658-53047-0710 is a circular connector housing with 7 positions and a pitch of 1.25 mm.

  • Positions: 7
  • Pitch: 1.25 mm
  • Color: Natural
  • Row: Single
  • Orientation: Vertical
  • Housing Material: Polyamide
  • Contact Material: Tin
  • Contact Plating: Tin
  • Contact Resistance: 20 mΩ
  • Compliance: RoHS compliant and lead-free
  • Supply: Limited
  • Popularity: Medium
