53505-3071 Real Image
Same model may have multiple batches, images only for reference.

53505-3071

Part No 53505-3071
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description 1.25mm Pitch Pico-Gold™ Wire-to-Board Header, Surface Mount, Dual Row, Vertical, 30 Circuits
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Connector Type Male Pin
Contact Material Bronze
Contact Plating Gold
Contact Resistance 20 mΩ
Depth 6 mm
Housing Material Polyphthalamide
Length 24.85 mm
Maximum Operating Temperature 85 °C
Max Voltage Rating (AC) 125 V
Min Operating Temperature -40 °C
Mount Surface Mount
Number of Circuits 30
Number of Contacts 30
Number of Positions 30
Number of Rows 2
Orientation Vertical
Pitch 1.2446 mm
RoHS Compliant
Row Spacing 1.397 mm
Termination Solder
Win Source Part Number 1033727-53505-3071
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 53505-3071 CAD Model

Description

The Molex, LLC 1033727-53505-3071 is a male pin surface mount connector with 30 positions and 2 rows.

  • Pitch: 1.2446mm
  • Row Spacing: 1.397mm
  • Contact Material: bronze
  • Contact Plating: gold
  • Housing Material: polyphthalamide
  • Maximum Operating Temperature: 85°C
  • Supply and Demand Status: shortage
