535170410 Real Image
Same model may have multiple batches, images only for reference.

535170410

Part No 535170410
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Header Connector, pcb Mount, recept, 4 Contacts, pin, 0.098 Pitch, pc Tail W/retnn Terminal, locking
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Natural
Connector Type Male Pin
Contact Material Bronze, Copper, Tin
Contact Mating Length 3.9878 mm
Contact Plating Tin
Country of Origin JP
Current Rating 3 A
Depth 6.8 mm
Fastening Type Ramp
Height 17.75 mm
Housing Color Natural
Housing Material Polyamide
Length 12.4 mm
Max Operating Temperature 105 °C
Min Operating Temperature -40 °C
Mount Through Hole
Number of Circuits 3
Number of Contacts 4
Number of Positions 4
Number of Rows 1
Orientation Vertical
Pitch 2.4892 mm
RoHS Compliant
Termination Solder
Voltage Rating 250 V
Win Source Part Number 1202917-535170410
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 535170410 CAD Model

Description

The Molex LLC 1202917-535170410 is a through hole male circular connector housing with 4 positions and 1 row.

  • Pitch: 2.4892 mm
  • Voltage Rating: 250 V
  • Current Rating: 3 A
  • Contact Plating: tin
  • RoHS Compliant: Yes
  • Suitable for: Circular connector housings
  • Orientation: vertical
  • Series: 53517
  • Popularity: Medium
  • Supply: Limited
