53625-0474 Real Image
Same model may have multiple batches, images only for reference.

53625-0474

Part No 53625-0474
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn High Speed Champ Docking PL 40 POS 0.5mm Solder ST Thru-Hole/SMD 40 Terminal 1 Port
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Natural
Contact Material Bronze, Copper
Contact Plating Gold
Country of Origin JP
Current Rating 500 mA
Gender Male
Glow Wire Compliant Non-compliant
Housing Material Thermoplastic
Lead Pitch 640 µm
Maximum Operating Temperature 85 °C
Min Operating Temperature -55 °C
Mount Surface Mount
Number of Circuits 40
Number of Contacts 40
Number of Positions 40
Number of Rows 2
Orientation Vertical
Pitch 640 µm
Plating Tin
REACH SVHC Unknown
RoHS Compliant
Termination SMD/SMT
Voltage Rating 100 V
Voltage Rating (DC) 100 V
Win Source Part Number 1019634-53625-0474
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 53625-0474 CAD Model

Description

The 53625-0474 is a 40-position vertical surface mount circular connector housing manufactured by Molex, LLC.

  • Maximum Voltage: 100V
  • Current: 500mA
  • Package: tape and reel
  • Plating: gold plating
