Same model may have multiple batches, images only for reference.
55299-1078 Real Image
Same model may have multiple batches, images only for reference.

55299-1078

Part No 55299-1078
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Connector, Stacking, Plug, 100 Position, 2ROW, 0.5MM
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Contact Material Brass
Contact Plating Gold
Current Rating 500 mA
Gender Male
Housing Material Thermoplastic
Lead Pitch 500 µm
Mount Surface Mount
Number of Contacts 100
Number of Positions 100
Number of Rows 2
Pitch 500 µm
REACH SVHC Unknown
RoHS Compliant
Row Spacing 3 mm
Termination SMD/SMT
Voltage Rating 50 V
Win Source Part Number 1039282-55299-1078
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 55299-1078 CAD Model

Description

The Molex 1039282-55299-1078 is a 100-position male circular connector housing that is designed to be used in circular connector applications. Bold the product name Molex 1039282-55299-1078.

  • Type: 100-position male circular connector housing
  • Applications: circular connector applications
  • Material: thermoplastic material
  • Contact Plating: gold contact plating
  • Pitch: 500 µm
  • Voltage Rating: 50 V
  • Current Rating: 500 mA
  • Contact Material: brass
  • Termination: SMD/SMT
  • RoHS: compliant
  • GPTDescription: suitable for use in a variety of applications, including industrial and telecommunications.
