Same model may have multiple batches, images only for reference.
55917-1630 Real Image
Same model may have multiple batches, images only for reference.

55917-1630

Part No 55917-1630
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description 2.00mm Pitch MicroClasp WTB Header Dual Row Vertical 16 Circuits without PCB Locator
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color White
Contact Material Brass
Contact Plating Tin
Contact Resistance 20 mΩ
Country of Origin VN
Current Rating 3 A
Flammability Rating UL94 V-0
Gender Male
Glow Wire Compliant Non-compliant
Housing Material Polyester
Insulation Resistance 1 GΩ
Lead Pitch 2 mm
Material Glass, Polyester
Max Current Rating 3 A
Max Operating Temperature 85 °C
Min Operating Temperature -25 °C
Mount Through Hole
Number of Circuits 16
Number of Contacts 16
Number of Poles 16
Number of Positions 16
Number of Rows 2
Orientation Vertical
Pitch 2 mm
Plating Tin
REACH SVHC No SVHC
RoHS Compliant
Termination Through Hole
Voltage Rating 250 V
Voltage Rating (AC) 250 V
Working Voltage 250 V
Win Source Part Number 1230753-55917-1630
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 55917-1630 CAD Model

Description

The Molex 1230753-55917-1630 is a 16-position through-hole connector with a pitch of 2mm and a male gender.

  • Pitch: 2mm
  • Gender: Male
  • Voltage Rating: 250V
  • Current Rating: 3A
  • Contact Material: Brass
  • Housing Material: Polyester
  • Contact Plating: Tin
  • Housing Color: White
  • Contact Resistance: 20 mΩ
  • Height: 0.362" (9.20mm)
  • Application: Suitable for use in circular connector housings
  • RoHS Compliant: Yes
  • Minimum Operating Temperature: -25 °C
  • Maximum Operating Temperature: 85 °C
