Same model may have multiple batches, images only for reference.
70555-0043 Real Image
Same model may have multiple batches, images only for reference.

70555-0043

Part No 70555-0043
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn Shrouded Header (4 Sides) HDR 9 POS 2.54mm Solder RA Side Entry Thru-Hole SL™ Tube
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Black
Connector Type Male Pin
Contact Material Bronze
Contact Mating Length 6.096 mm
Contact Plating Gold
Contact Resistance 30 mΩ
Country of Origin US
Current Rating 3 A
Depth 13.59 mm
Housing Color Black
Housing Material Polyester
Length 26.31 mm
Material Brass
Maximum Operating Temperature 105 °C
Min Operating Temperature -40 °C
Mount Through Hole
Number of Circuits 8
Number of Positions 9
Number of Rows 1
Orientation Right Angle
Pitch 2.54 mm
Plating Tin
Radiation Hardening No
RoHS Compliant
Termination Solder
Win Source Part Number 997136-70555-0043
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 70555-0043 CAD Model

Description

The Molex 997136-70555-0043 is a right-angle, male pin circular connector housing.

  • Circuits: 8
  • Current Rating: 3 A
  • Length: 26.31 mm
  • Depth: 13.59 mm
  • RoHS Compliant: Yes
  • Radiation Hardening: not required
  • Category: Circular Connectors - Housings
