Same model may have multiple batches, images only for reference.
74320-3000 Real Image
Same model may have multiple batches, images only for reference.

74320-3000

Part No 74320-3000
Manufacturer Molex, LLC
Catalog Barrel - Audio Connectors
Description Heavy Duty Connector Insert, Modice Series, 30, 3, Socket Rohs Compliant: Yes
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Body Material Metal
Mounting SMD (SMT)
Case / Package Metal
Color Natural
Connector Type DVI
Contact Material Copper
Contact Plating Gold
Country of Origin US
Current Rating 3 A
Depth 9.91 mm
Gender Receptacle
Housing Material Polymer
Insulation Resistance 1 GΩ
Lead Pitch 2.54 mm
Length 36.83 mm
Maximum Operating Temperature 85 °C
Max Voltage Rating (AC) 40 V
Min Operating Temperature -20 °C
Mount Through Hole
Number of Circuits 29
Number of Contacts 29
Number of Ports 1
Number of Positions 29
Number of Rows 3
Number of Terminals 29
Orientation Vertical, Right Angle
Pitch 1.91 mm
Plating Tin
Radiation Hardening No
REACH SVHC Unknown
RoHS Compliant
Termination Solder
Voltage Rating 40 V
Voltage Rating (AC) 40 V
Weight 5.81701 g
Width 11.48 mm
Win Source Part Number 1031452-74320-3000
Categories Barrel - Audio Connectors
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 74320-3000 CAD Model

Description

The Molex 1031452-74320-3000 is a 29-position, 3-row surface mount receptacle connector. The manufacturer is Molex.

  • Positions: 29
  • Rows: 3
  • Mounting: surface mount
  • Pitch: 1.91 mm
  • Length: 36.83 mm
  • Housing Material: polymer
  • Contact Material: copper with gold plating
  • Current Rating: 3 A
  • Voltage Rating: 40 V
  • Contacts: 29
  • Insulation Resistance: 1 GΩ
  • RoHS Compliant: Yes
  • Applications: audio connectors
