76650-0009 Real Image
Same model may have multiple batches, images only for reference.

76650-0009

Part No 76650-0009
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Headers, .100KK Connector Kit Prem Crimptool 184PC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Mounting SMD (SMT)
Case / Package 100
Connector Type Receptacle
Contact Gender Male
Current Rating 2.5 A
Height 47.625 mm
Lead Free Yes
Length 323.85 mm
Mount Through Hole
Number of Pins 68
Operating Supply Voltage 250 V
Pitch 2.54 mm
RoHS Compliant
Termination Through Hole
Voltage Rating 250 V
Weight 680.388555 g
Width 152.4 mm
Wire Gauge (Max) 22 AWG
Wire Gauge (Min) 30 AWG
Win Source Part Number 1012157-76650-0009
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 76650-0009 CAD Model

Description

The Molex, LLC 1012157-76650-0009 is a through-hole receptacle connector with a pitch of 2.54 mm.

  • Voltage Rating: 250 V
  • Current Rating: 2.5 A
  • Male Pins: 68
  • Mounting: SMD (SMT) technology
  • Length: 323.85 mm
  • Width: 152.4 mm
  • Height: 47.625 mm
  • RoHS Compliant: Yes
  • Lead-Free: Yes
  • Wire Gauge Range: 30-22 AWG
