The Molex 90142-0028 is a shrouded header from the Mini-Fit Jr. connector series. It's designed for wire-to-board connections, providing a reliable and secure interface for power and signal transmission in a variety of electronic applications.

Applications

• Power Supplies
• Industrial Equipment
• Appliances
• Automotive
• Medical Devices
• Networking Equipment

Features

• Mini-Fit Jr. compatibility
• Dual Row
• 28 Circuits
• Shrouded Header Design
• Polarization to prevent mismating
• Positive Lock

Benefits

• Provides a reliable and secure connection
• Prevents accidental disconnections
• Supports high-density applications
• Reduces the risk of short circuits and electrical damage
• Ensures proper mating alignment
• Simplifies assembly

Technical Specifications

The Molex 90142-0028 is a 28-circuit, dual-row shrouded header. The 'shrouded' design refers to the plastic housing surrounding the pins, which provides additional protection and helps prevent accidental damage or short circuits. The housing also incorporates polarization features to ensure correct mating with a compatible receptacle. It utilizes a positive locking mechanism to secure the connection and prevent accidental disconnections due to vibration or other environmental factors. The Mini-Fit Jr. series is known for its robust design and ability to handle both power and signal circuits. The connector pitch (distance between pins) is a standard dimension for the Mini-Fit Jr. series. It is designed to be soldered onto a printed circuit board (PCB). Proper soldering techniques and equipment are essential for ensuring a reliable connection.
