MP2735DQG-LF-Z Monolithic Power Systems Inc. – Price, Stock & Datasheet MP2735DQG-LF-Z Real Image
Same model may have multiple batches, images only for reference.
MP2735DQG-LF-Z Monolithic Power Systems Inc. – Price, Stock & Datasheet MP2735DQG-LF-Z Real Image
MP2735DQG-LF-Z Monolithic Power Systems Inc. – Price, Stock & Datasheet MP2735DQG-LF-Z Real Image
Same model may have multiple batches, images only for reference.

MP2735DQG-LF-Z

Part No MP2735DQG-LF-Z
Manufacturer Monolithic Power Systems Inc.
Catalog Interface - Analog Switches, Multiplexers, Demultiplexers
Description IC SWITCH SPDT X 2 450MOHM 10QFN
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Package Tape & Reel (TR)
Product Status Active
Switch Circuit SPDT
Number of Circuits 2
On-State Resistance (Max) 450mOhm
Channel-to-Channel Matching (ΔRon) 10mOhm
Voltage - Supply, Single (V+) 1.65V ~ 5.5V
Switch Time (Ton, Toff) (Max) 36ns, 30ns
-3db Bandwidth 50MHz
Channel Capacitance (CS(off), CD(off)) 55pF
Current - Leakage (IS(off)) (Max) 40nA
Crosstalk -70dB @ 100kHz
Operating Temperature -40°C ~ 85°C (TA)
Mounting Type Surface Mount
Package / Case 10-VFQFN
Supplier Device Package 10-QFN (1.4x1.8)
Ultra Librarian 3D Model Ultra Librarian MP2735DQG-LF-Z CAD Model

Description

The Monolithic Power Systems Inc. SPDT Switch Circuit is a surface mount regulator with a bandwidth of 50MHz.

  • Single Supply Voltage: 1.65V to 5.5V
  • Package: 10-QFN (1.8x1.4)
  • Features: charge injection, crosstalk of -70dB @ 100kHz
  • Channel-to-Channel Matching (ΔRon): 10mOhm
  • On-State Resistance (maximum): 450mOhm
  • Switch Time (Ton, Toff) (maximum): 36ns, 30ns
  • Current Leakage (IS(off)) (maximum): 40nA
  • Supply and Demand Status: balance
  • Manufacturer Pack Quantity: 5,000
  • MSL Level: 1 (Unlimited)
