Same model may have multiple batches, images only for reference.

MP5087AGG-Z

Name: MP5087AGG-Z
Brand: Monolithic Power Systems Inc.
SKU: 239079
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

Part No	MP5087AGG-Z
Manufacturer	Monolithic Power Systems Inc.
Catalog	PMIC - Power Distribution Switches, Load Drivers
Description	IC PWR SWITCH P-CHAN 1:1 12QFN
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Package	Tape & Reel (TR);Cut Tape (CT);
Product Status	Active
Switch Type	General Purpose
Number of Outputs	1
Output Configuration	High Side
Output Type	P-Channel
Interface	On/Off
Voltage - Load	0.5V ~ 5.5V
Voltage - Supply (Vcc/Vdd)	3V ~ 5.5V
Current - Output (Max)	7A
Rds On (Typ)	10mOhm
Features	Load Discharge, Power Good, Slew Rate Controlled
Fault Protection	Current Limiting (Adjustable), Over Temperature, UVLO
Operating Temperature	-40°C ~ 125°C (TJ)
Mounting Type	Surface Mount
Supplier Device Package	12-QFN (2x2)
Package / Case	12-VFQFN
Ultra Librarian 3D Model	Ultra Librarian MP5087AGG-Z CAD Model

Alternative Products

Description

Monolithic Power Systems Inc. produces the MP5087AGG-Z, an integrated circuit with a P-channel output type and a slew rate controlled feature.

Output Type: P-channel
Feature: Slew Rate Controlled
Features: Load Discharge, Power Good
Fault Protection: Current Limiting (Adjustable), Over-Temperature, UVLO
Maximum Current Output: 7A
Voltage Load Range: 0.5V to 5.5V
Application: General-Purpose
Rds On (Typ): 10 mOhm
Case/Package: 12-QFN (2x2)
Operating Temperature: -40°C to 125°C (TJ)
Status: Active
