IF0505S-1WR3 MORNSUN Science& Technology Ltd. – Price, Stock & Datasheet IF0505S-1WR3 Real Image
Same model may have multiple batches, images only for reference.
IF0505S-1WR3 MORNSUN Science& Technology Ltd. – Price, Stock & Datasheet IF0505S-1WR3 Real Image
IF0505S-1WR3 MORNSUN Science& Technology Ltd. – Price, Stock & Datasheet IF0505S-1WR3 Real Image
Same model may have multiple batches, images only for reference.

IF0505S-1WR3

Part No IF0505S-1WR3
Catalog Power Supplies Board Mount DCDC Converters
Description DC DC CONVERTER 5V 1W
Sample
Rohs State rohs
Need Help

Products specifications Report Issue?

Package Tube
Product Status Not For New Designs
Type Isolated Module
Number of Outputs 1
Voltage - Input (Min) 4.75V
Voltage - Input (Max) 5.25V
Voltage - Output 1 5V
Current - Output (Max) 200mA
Power (Watts) 1 W
Voltage - Isolation 3 kV
Applications ITE (Commercial)
Operating Temperature -40°C ~ 85°C (With Derating)
Efficiency 70%
Mounting Type Through Hole
Package / Case 7-SIP Module, 4 Leads
Size / Dimension 0.77" L x 0.24" W x 0.40" H (19.7mm x 6.0mm x 10.2mm)
Approval Agency CB, CE, cURus, UKCA
Standard Number 62368-1
Ultra Librarian 3D Model Ultra Librarian IF0505S-1WR3 CAD Model

Description

The MORNSUN Science & Technology Ltd. IF0505S-1WR3 is an isolated module DC-DC converter that is designed for use in ITE (Commercial) applications.

  • Power Output: 1 W
  • Efficiency: 70 percent
  • Voltage Isolation: 3 kV
  • Current Output: 200mA
