Same model may have multiple batches, images only for reference.
URA2424YMD-6WR3 MORNSUN Science& Technology Ltd.
Same model may have multiple batches, images only for reference.

URA2424YMD-6WR3

Part No URA2424YMD-6WR3
Catalog Power Supplies Board Mount DCDC Converters
Description DC DC CONVERTER +/-24V 6W
Sample
Rohs State rohs
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount - DC DC Converters
Mfr Mornsun America, LLC
Series URA_YMD-6WR3 (6W)
Package Tube
Product Status Active
Type Isolated Module
Number of Outputs 2
Voltage - Input (Min) 9V
Voltage - Input (Max) 36V
Voltage - Output 1 24V
Voltage - Output 2 -24V
Voltage - Output 3 -
Voltage - Output 4 -
Current - Output (Max) 125mA, 125mA
Power (Watts) 6 W
Voltage - Isolation 1.5 kV
Applications ITE (Commercial)
Features -
Temperature Range - Operating -40°C ~ 85°C (With Derating)
Efficiency 87%
Mounting Type Through Hole
Package / Case 5-DIP Module
Size / Dimension 1.00" L x 1.00" W x 0.46" H (25.4mm x 25.4mm x 11.7mm)
Supplier Device Package -
Control Features -
Approval Agency CB, CE, cURus
Base Product Number URA2424
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.40.9580
Win Source Part Number 1372755-URA2424YMD-6WR3
Ultra Librarian 3D Model Ultra Librarian URA2424YMD-6WR3 CAD Model

Description

The URA2424YMD-6WR3 is a 6W isolated module DC-DC converter manufactured by Mornsun America, LLC.

  • Output Type: Isolated
  • Voltage - Output 1: 24V
  • Voltage - Output 2: -24V
  • Current - Output 1: 125mA
  • Voltage - Input (Min): 9V
  • Voltage - Input (Max): 36V
  • Power (Watts): 6W
  • Applications: ITE (Commercial)
  • Efficiency: 87%
  • Voltage - Isolation: 1.5 kV
  • Mounting Type: Through Hole
  • Package / Case: 5-DIP Module
  • Size / Dimension: 1.00" L x 1.00" W x 0.46" H (25.4mm x 25.4mm x 11.7mm)
  • Approval Agency: CB, CE, cURus
