WRA2412S-1WR2 MORNSUN Science& Technology Ltd.
Same model may have multiple batches, images only for reference.

WRA2412S-1WR2

Part No WRA2412S-1WR2
Catalog Power Supplies Board Mount DCDC Converters
Description ISOLATED MODULE DC DC CONVERTER
Sample
Rohs State rohs
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount - DC DC Converters
Mfr MORNSUN Science& Technology Ltd.
Series WRA_S-1WR2 (1W)
Package Tube
Product Status Active
Type Isolated Module
Number of Outputs 2
Voltage - Input (Min) 18V
Voltage - Input (Max) 36V
Voltage - Output 1 12V
Voltage - Output 2 -12V
Current - Output (Max) 42mA, 42mA
Power (Watts) 1 W
Voltage - Isolation 1.5 kV
Applications ITE (Commercial)
Features Remote On/Off
Temperature Range - Operating -40°C ~ 85°C
Efficiency 78%
Mounting Type Through Hole
Package / Case 8-SIP Module, 7 Leads
Size / Dimension 0.87" L x 0.37" W x 0.47" H (22.0mm x 9.5mm x 12.0mm)
Approval Agency CE, EN, UKCA
Standard Number 62368-1
Standard Package 22 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.40.9580
Win Source Part Number 697824-WRA2412S-1WR2
Ultra Librarian 3D Model Ultra Librarian WRA2412S-1WR2 CAD Model

Description

The 697824-WRA2412S-1WR2 is a power supply module designed by MORNSUN Science & Technology Ltd.

  • Series: WRA_S-1WR2 (1W)
  • Size: 0.87" L x 0.37" W x 0.47" H (22.0mm x 9.5mm x 12.0mm)
  • Power Output: 1W
  • Functionality: Remote on/off
  • Voltage Isolation: 1.5 kV
  • Outputs: Two
  • Maximum Output Current: 42mA each
  • Input Voltage: 18V to 36V
  • Output Voltages: 12V and -12V
  • Efficiency: 78%
  • Applications: ITE (Commercial)
  • Mounting: Through hole
  • Package: 8-SIP module with 7 leads
  • Operating Temperature: -40°C to 85°C
  • Compliance: CE, EN, and UKCA standards
