Same model may have multiple batches, images only for reference.

48220C

Name: 48220C
Brand: Murata Power Solutions Inc.
SKU: 999964
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

Part No	48220C
Manufacturer	Murata Power Solutions Inc.
Catalog	Fixed Inductors
Description	FIXED IND 22UH 2.6A 119MOHM SMD / 22 µH Shielded Wirewound Inductor 2.6 A 119mOhm Max Nonstandard, 4 Lead
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Inductors, Coils, Chokes>Fixed Inductors
Mfr	Murata Power Solutions Inc.
Series	4800
Package	Tape & Reel (TR)
Type	Wirewound
Inductance	22 µH
Current Rating (Amps)	2.6 A
Shielding	Shielded
DC Resistance (DCR)	119mOhm Max
Temperature Range - Operating	-40°C ~ 85°C
Inductance Frequency - Test	10 kHz
Mounting	SMD (SMT)
Package / Case	Nonstandard, 4 Lead
Dimension	0.480" L x 0.480" W (12.20mm x 12.20mm)
Height - Seated (Max)	0.244" (6.20mm)
Base Product Number	48
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.50.4000
Standard Package	600
Win Source Part Number	999964-48220C
Ultra Librarian 3D Model	Ultra Librarian 48220C CAD Model

Alternative Products

Description

This is a wirewound inductor with a shielded package and a nonstandard 4-lead package/case.

Package: Shielded
Package/Case: Nonstandard 4-lead
Inductance: 22 µH
Maximum DC Resistance: 119mOhm
Inductance Frequency-Test: 10 kHz
Maximum Height: 0.244" (6.20mm) when seated
Series: 4800
Current Rating: 2.6 A
Operating Temperature Range: -40°C ~ 85°C
Manufacturer: Murata Power Solutions Inc.
