DA103C Real Image
Same model may have multiple batches, images only for reference.

DA103C

Part No DA103C
Manufacturer Murata Power Solutions Inc.
Catalog Pulse Transformers
Description DIGITAL AUDIO TX 1:1 5MH DIP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Transformers - Pulse Transformers
Mfr Murata Power Solutions Inc.
Series DA100
Package Box
Product Status Active
Inductance 7.75mH
ET (Volt-Time) 28VµS
Mounting Type Through Hole
Size / Dimension 0.354" L x 0.375" W (9.00mm x 9.52mm)
Height - Seated (Max) 0.250" (6.35mm)
Temperature Range - Operating -40°C ~ 85°C
Base Product Number DA103
Standard Package 50 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.31.2000
Win Source Part Number 583613-DA103C
Ultra Librarian 3D Model Ultra Librarian DA103C CAD Model

Description

The 583613-DA103C is a pulse transformer from the DA100 series by Murata Power Solutions Inc.

  • Package: Box
  • Size: 0.354" L x 0.375" W (9.00mm x 9.52mm)
  • Inductance: 7.75mH
  • Height: 0.250" (6.35mm)
  • Mounting: Through-Hole
  • Operating Temperature: -40°C to 85°C
