The NT5CB128M16IP-EK is a DDR3 SDRAM (Double Data Rate 3 Synchronous Dynamic Random-Access Memory) module manufactured by NANYA. This component is designed to offer high-speed data transfer rates with relatively low power consumption, making it suitable for a wide range of applications, from desktop computers to embedded systems.

Applications

• Desktop Computers
• Laptop Computers
• Embedded Systems
• Networking Devices
• Graphics Cards

Features

• Memory Size: 2Gb (128M x 16)
• Interface: DDR3 SDRAM
• Operating Voltage: 1.5V
• Data Transfer Rate: Up to 1866 MT/s (MegaTransfers per second)
• 8 Internal Banks for concurrent operations
• On-Die Termination (ODT) to improve signal integrity
• RoHS Compliant (Lead-Free)

Benefits

• High Bandwidth: Provides fast data access for improved system performance.
• Low Power Consumption: Reduces energy usage, contributing to longer battery life in portable devices and lower operating costs.
• Enhanced System Responsiveness: Enables quicker loading times and smoother multitasking.
• Improved Signal Integrity: Ensures reliable data transfer and stable performance.
• Wide Compatibility: Works with a variety of platforms supporting DDR3 memory.

Additional Details

The NT5CB128M16IP-EK DDR3 SDRAM module utilizes an 8-bank architecture, allowing for concurrent operations to maximize data throughput. The on-die termination (ODT) feature significantly improves signal integrity, reducing signal reflections and noise, which is crucial for stable performance at high data rates. This memory module adheres to JEDEC standards, ensuring compatibility and reliability. It is packaged in a FBGA (Fine-pitch Ball Grid Array) package for efficient surface mounting and minimized board space. The RoHS compliance indicates that the module is manufactured without hazardous substances, aligning with environmental regulations. This memory module is well-suited for applications demanding high performance, low power consumption, and reliable operation.
