LP3986BL-3131 Real Image
Same model may have multiple batches, images only for reference.

LP3986BL-3131

Part No LP3986BL-3131
Manufacturer National Semiconductor (TI)
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LINEAR FIXED LDO REG
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Power Management (PMIC) - Voltage Regulators - Linear
Mfr National Semiconductor (TI)
Package Bulk
Product Status Active
Output Configuration Positive
Output Type Fixed
Number of Regulators 2
Voltage - Input (Max) 6V
Voltage - Output (Min/Fixed) 3.1V
Voltage Dropout (Max) 0.1V @ 150mA
Current - Output 150mA
Current - Quiescent (Iq) 130 µA
Current - Supply (Max) 320 µA
PSRR 60dB ~ 50dB (1kHz ~ 10kHz)
Control Features Enable
Protection Features Over Current, Over Temperature, Short Circuit
Temperature Range - Operating -40°C ~ 125°C
Mounting Type Surface Mount
Package / Case 8-TFBGA
Supplier Device Package 8-µSMD (1.57x1.57)
Standard Package 217 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 923621-LP3986BL-3131
Ultra Librarian 3D Model Ultra Librarian LP3986BL-3131 CAD Model

Description

The LP3986BL-3131 is a voltage regulator IC from National Semiconductor (TI). It is designed for power management applications and offers a fixed output voltage of 3.1V.

  • Output Voltage: 3.1V
  • Package: 8-TFBGA
  • Temperature Range: -40°C to 125°C
  • Output Current (Max): 150mA
  • Supply Current: 320µA
  • Protection: Over-Current, Over-Temperature, Short-Circuit
  • PSRR: 60dB to 50dB
