74AHCT04APWJ Nexperia USA Inc. – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

74AHCT04APWJ

Part No 74AHCT04APWJ
Manufacturer Nexperia USA Inc.
Catalog Logic - Gates and Inverters
Description IC INVERTER 6CH 1-INP 14TSSOP
Datasheet
74AHCT04APWJ Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Logic Type Inverter
Number of Circuits 6
Number of Inputs 1
Voltage - Supply 4.5V ~ 5.5V
Current - Quiescent (Max) 75 mA
Current - Output High, Low 8mA, 8mA
Input Logic Level - Low 0.1V ~ 0.36V
Input Logic Level - High 3.94V ~ 4.5V
Max Propagation Delay @ V, Max CL 7.7ns @ 5V, 50pF
Temperature Range - Operating -40°C ~ 125°C (TA)
Mounting Type Surface Mount
Supplier Device Package 14-TSSOP
Case / Package 14-TSSOP (0.173\
Package Tape & Reel
Supply and Demand Status Shortage
Win Source Part Number 1507041-74AHCT04APWJ
Ultra Librarian 3D Model Ultra Librarian 74AHCT04APWJ CAD Model
