74HCT595D NXP 74HCT595D label picture
Same model may have multiple batches, images only for reference.
74HCT595D NXP 74HCT595D label picture
74HCT595D NXP 74HCT595D label picture
Same model may have multiple batches, images only for reference.

74HCT595D

Part No 74HCT595D
Manufacturer Nexperia USA Inc.
Catalog Logic - Shift Registers
Description SERIAL IN PARALLEL OUT, HCT SERI / Shift Shift Register 1 Element 8 Bit 16-SO
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Logic - Shift Registers
Mfr Nexperia USA Inc.
Series 74HCT
Package Bulk
Product Status Active
Logic Type Shift Register
Output Type Tri-State
Number of Elements 1
Number of Bits per Element 8
Function Serial to Parallel, Serial
Voltage - Supply 4.5V ~ 5.5V
Temperature Range - Operating -40°C ~ 125°C
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154", 3.90mm Width)
Supplier Device Package 16-SO
Base Product Number 74HCT595
Standard Package 1 pcs
HTSUS 0000.00.0000
Win Source Part Number 549585-74HCT595D
Ultra Librarian 3D Model Ultra Librarian 74HCT595D CAD Model

Description

The 549585-74HCT595D is a shift register integrated circuit (IC) from Nexperia USA Inc.

  • Series: 74HCT
  • Function: Logic shift registers
  • Voltage Supply Range: 4.5V to 5.5V
  • Mounting Type: Surface mountable
  • Package: 16-SOIC
  • Temperature Range: -40°C to 125°C
  • ECCN: EAR99
  • HTSUS Code: 0000.00.0000
