Same model may have multiple batches, images only for reference.
74LVT16245BBX,518 Nexperia USA Inc.
Same model may have multiple batches, images only for reference.

74LVT16245BBX,518

Part No 74LVT16245BBX,518
Manufacturer Nexperia USA Inc.
Catalog Logic - Buffers, Drivers, Receivers, Transceivers
Description IC TXRX 16BIT 3.3V 3ST 60HXQFN
Datasheet
74LVT16245BBX,518 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Nexperia USA Inc.
Series 74LVT
Packaging Reel package
Logic Type Transceiver, Non-Inverting
Number of Elements 2
Number of Bits per Element 8
Output Type Push-Pull
Current - Output High, Low 32mA, 64mA
Operating Supply Voltage 2.7 V ~ 3.6 V
Operating Temperature Range -40°C ~ 125°C (TA)
Mounting SMD
Package 60-XFQFN Dual Rows, Exposed Pad
Manufacturer Package 60-HXQFN (4x6)
Win Source Part Number 765841-74LVT16245BBX,518
Popularity Medium
Supply and Demand Status Limited
Family Name 74LVT16245
Introduction Date May 23, 1994
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date Obsolete
Ultra Librarian 3D Model Ultra Librarian 74LVT16245BBX,518 CAD Model

Description

The Nexperia USA Inc. 74LVT16245BBX,518 is a transceiver, non-inverting logic type IC with a push-pull output type from Nexperia USA Inc.

  • Voltage Range: 2.7V to 3.6V
  • Current Output High and Low: 32mA and 64mA
  • Package: 60-XFQFN Dual Rows, Exposed Pad
  • Mounting: SMD
  • Alternative part (cross-reference): 74LVT16245BEVE, 74LVT16245BEV,518, and 74LVT16245BEVK
  • Introduction date: May 23, 1994
