Same model may have multiple batches, images only for reference.

BUK9M15-40HX

Name: BUK9M15-40HX
Brand: Nexperia USA Inc.
SKU: 961598
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	BUK9M15-40HX
Manufacturer	Nexperia USA Inc.
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET N-CH 40V 30A LFPAK33 / N-Channel 40 V 30A (Ta) 44W (Ta) Surface Mount LFPAK33
Datasheet	BUK9M15-40HX Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Discrete Semiconductor Products>Transistors - FETs, MOSFETs - Single
Mfr	Nexperia USA Inc.
Series	Automotive, AEC-Q101
Package	Tape & Reel
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	40 V
Current - Continuous Drain (Id) @ 25°C	30A (Ta)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Rds On (Max) @ Id, Vgs	15mOhm @ 10A, 10V
Vgs(th) (Max) @ Id	2.2V @ 1mA
Gate Charge (Qg) (Max) @ Vgs	16.2 nC @ 10 V
Vgs (Max)	±16V
Input Capacitance (Ciss) (Max) @ Vds	1026 pF @ 25 V
Power Dissipation (Max)	44W (Ta)
Temperature Range - Operating	-55°C ~ 175°C (TJ)
Mounting	SMD (SMT)
Supplier Device Package	LFPAK33
Package / Case	SOT-1210, 8-LFPAK33 (5-Lead)
Base Product Number	BUK9M15
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8541.29.0095
Other Names	1727-8678-2,1727-8678-1,1727-8678-6,934660798115
Standard Package	1,500
Win Source Part Number	961598-BUK9M15-40HX
Ultra Librarian 3D Model	Ultra Librarian BUK9M15-40HX CAD Model

Alternative Products

Description

Nexperia USA Inc. offers a MOSFET transistor, part number 961598-BUK9M15-40HX.

Type: N-channel
Drain to Source Voltage: 40V
Continuous Drain Current @ 25°C: 30A
Rds On (Max) @ Id, Vgs: 15mOhm @ 10A, 10V
Gate Charge (Qg) (Max) @ Vgs: 16.2 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 1026 pF @ 25 V
Operating Temperature Range: -55°C to 175°C (TJ)
Package: tape & reel package with standard packaging of 1,500 units
Alternative parts (cross-reference): not specified
Manufacturer Part Number: 934660798115
