PMEG3020EH,115

Part No PMEG3020EH,115
Manufacturer Nexperia USA Inc.
Catalog Diodes, Rectifiers - Single
Description DIODE SCHOTTKY 30V 2A SOD123F
Datasheet
PMEG3020EH,115 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Nexperia USA Inc.
Packaging Reel - TR
Status Active
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 30V
Current - Average Rectified (Io) 2A (DC)
Voltage - Forward (Vf) (Max) @ If 620mV @ 2A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 1mA @ 30V
Capacitance @ Vr, F 72pF @ 1V, 1MHz
Mounting SMD (SMT)
Case / Package SOD-123F
Operating Temperature - Junction 150°C (Max)
Win Source Part Number 1089599-PMEG3020EH,115
Popularity Medium
Supply and Demand Status Sufficient
Application Field Used in Power Management, Industrial
Ultra Librarian 3D Model Ultra Librarian PMEG3020EH,115 CAD Model

Description

The Nexperia USA Inc. PMEG3020EH,115 is a Schottky diode that comes in a SMD (SMT) package.

  • Maximum DC Reverse Voltage: 30V
  • Average Rectified Current: 2A (DC)
  • Forward Voltage: 620mV @ 2A
  • Reverse Leakage Current: 1mA @ 30V
  • Capacitance: 72pF @ 1V, 1MHz
  • Operating Temperature: Up to 150°C (Max)
