NJM3717E2 NJR Corporation/NJRC
Same model may have multiple batches, images only for reference.

NJM3717E2

Part No NJM3717E2
Manufacturer Nisshinbo Micro Devices Inc.
Catalog PMIC - Motor Drivers, Controllers
Description IC STEPPER MOTOR DRIVER 20EMP
Datasheet
NJM3717E2 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Power Management (PMIC) - Motor Drivers, Controllers
Mfr Nisshinbo Micro Devices Inc.
Package Tube
Product Status Obsolete
Motor Type - Stepper Bipolar
Function Driver - Fully Integrated, Control and Power Stage
Output Configuration Half Bridge (2)
Interface Parallel
Technology Bipolar
Step Resolution 1, 1/2
Applications General Purpose
Current - Output 1A
Voltage - Supply 4.75V ~ 5.25V
Voltage - Load 10V ~ 45V
Temperature Range - Operating -40°C ~ 150°C (TJ)
Mounting Type Surface Mount
Package / Case 20-SOIC (0.209", 5.30mm Width)
Supplier Device Package 20-SOP
Base Product Number NJM3717
Standard Package 40 pcs
ECCN OBSOLETE
Win Source Part Number 255449-NJM3717E2
Ultra Librarian 3D Model Ultra Librarian NJM3717E2 CAD Model

Description

The NJM3717E2 is a fully integrated motor driver and controller integrated circuit (IC) designed for general-purpose motor control applications. It comes in a tube package with a standard package of 40 pieces.

  • Supply Voltage Range: 4.75V to 5.25V
  • Mounting Type: surface mount
  • Suitable for: bipolar stepper motors
  • Current Output: 1A
  • Manufacturer: Nisshinbo Micro Devices Inc.
  • Series: NJM3717
  • Temperature Range: -40°C to 150°C
  • ECCN: OBSOLETE
  • Description: The NJM3717E2 is a reliable and efficient motor driver and controller for various motor control applications.
