NJM7912FA Real Image NJM7912FA label picture NJM7912FA Real Image
Same model may have multiple batches, images only for reference.
NJM7912FA Real Image NJM7912FA label picture NJM7912FA Real Image
NJM7912FA Real Image NJM7912FA label picture NJM7912FA Real Image
Same model may have multiple batches, images only for reference.

NJM7912FA

Part No NJM7912FA
Manufacturer NJR Corporation/NJRC
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO -12V 1.5A TO220F
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer NJR Corporation/NJRC
Packaging Bulk
Status Active
Output Type Fixed
Number of Regulators 1
Maximum Input Voltage -35V
Nominal Output Voltage (Min/Fixed) -12V
Output Current 1.5A
Operating Supply Current 6mA
PSRR 68dB (120Hz)
Control Protection Features Over Temperature, Short Circuit
Temperature Range - Operating -40°C to 85°C
Regulator Topology Negative Fixed
Output Voltage -12V
Mounting Through Hole
Case / Package TO-220F
Win Source Part Number 041919-NJM7912FA
Popularity Medium
Supply and Demand Status Balance
Quantity per package 100
Ultra Librarian 3D Model Ultra Librarian NJM7912FA CAD Model

Description

The NJM7912FA is a negative fixed regulator that is manufactured by NJR Corporation/NJRC.

  • Output Voltage: -12V
  • Output Current: 1.5A
  • Package: TO-220F
  • Mounting: through hole
  • Regulator Topology: negative fixed
  • Number of Regulators: 1
  • Protection: over-temperature and short-circuit
  • Maximum Input Voltage: -35V
  • Nominal Output Voltage: -12V
  • Operating Supply Current: 6mA
  • PSRR: 68dB (120Hz)
  • Package Quantity: 100
  • Supply and Demand: balance
