Same model may have multiple batches, images only for reference.
NSM2012-20B3R-DSPR NOVOSENSE – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

NSM2012-20B3R-DSPR

Part No NSM2012-20B3R-DSPR
Manufacturer NOVOSENSE
Catalog Current Sensors
Description INTEGRATED CURRENT SENSOR
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Package Cut Tape (CT)
Product Status Active
For Measuring AC/DC
Sensor Type Hall Effect
Current - Sensing 20A
Number of Channels 1
Output Ratiometric, Voltage
Sensitivity 66mV/A
Frequency DC ~ 400kHz
Linearity ±0.2%
Accuracy ±2%
Voltage - Supply 3V ~ 3.6V
Response Time 1.5µs
Current - Supply (Max) 7.5mA
Operating Temperature -40°C ~ 125°C
Polarization Bidirectional
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154", 3.90mm Width)
Supplier Device Package 8-SOIC
Ultra Librarian 3D Model Ultra Librarian NSM2012-20B3R-DSPR CAD Model

Description

NULL
